Fronius TransTig 2500 User Manual

53
EN
Start-up
Safety
Remarks on the
cooling unit
We recommend using a cooling unit for the following applications and situations:
- JobMaster TIG welding torch
- Hosepacks over 5 m long
- TIG AC welding
- In general, where welding is performed in higher power ranges
The cooling unit is powered from the power source. The cooling unit is ready for operation
when the mains switch of the power source is in the "I" position.
More information on the cooling unit can be found in the operating instructions for the cool-
ing unit.
General This section describes how to commission the power source:
- for the main TIG welding application
- with reference to a standard configuration for a TIG welding device.
The standard configuration consists of the following system components:
- power source
- cooling unit
- TIG manual welding torch
- pressure regulator
- gas cylinder
- gas cylinder holder
- trolley
The steps set out below provide an overview of how to commission the power source.
For detailed information about the individual steps, please refer to the operating instruc-
tions for the system components.
Connecting the
gas cylinder
Secure the gas cylinder
Take the protective cap off the gas cylinder
Briefly open the gas cylinder valve to remove any dust or dirt
Check the seal on the pressure regulator
WARNING! An electric shock can be fatal. If the machine is plugged into the
mains electricity supply during installation, there is a high risk of very serious in-
jury and damage. Do not carry out any work on the device unless
- the mains switch is in the "O" position,
- the device is unplugged from the mains.
WARNING! If gas cylinders topple over, there is a risk of very serious injury and
damage.
- Place gas cylinders on a solid, level surface in such a way that they remain
stable
- Secure gas cylinders to prevent them from toppling over: fix the safety strap
at the same height as the top part of the cylinder
- Never fix the safety strap around the neck of the cylinder
Follow the gas cylinder manufacturer's safety instructions.
1
2
3
4
