Frontier TD2427 User Manual

21
TORQUE SPECIFICATIONS
NEWTON METERS (NM) FOOT POUNDS (FT. LBS.)
BOLT SIZE & PITCH CLASS PLATED UNPLATED PLATED UNPLATED
M4 x .70 8.8 3.10 2.20 2.30 1.65
M5 x .80 8.8 6.10 5.50 4.58 4.13
M6 x 1.00 8.8 10.40 9.50 7.80 7.13
M7 x 1.00 8.8 17.00 15.50 12.75 11.63
M8 x 1.25 8.8 25.00 23.00 18.75 17.25
M8 x 1.00 8.8 27.00 24.50 20.25 18.38
M10 x 1.50 8.8 51.00 46.00 38.25 34.50
M10 x 1.25 8.8 54.00 49.00 40.50 36.75
M10 x 1.00 8.8 57.00 52.00 42.75 39.00
M12 x 1.75 8.8 87.00 79.00 65.25 59.25
M12 x 1.50 8.8 92.00 83.00 69.00 62.25
M12 x 1.25 8.8 96.00 87.00 72.00 65.25
M14 x 2.00 8.8 140.00 125.00 105.00 93.75
M14 x 1.50 8.8 150.00 135.00 112.50 101.25
M16 x 2.00 8.8 215.00 195.00 161.25 146.25
M18 x 2.50 8.8 300.00 280.00 225.00 210.00
M20 x 2.50 8.8 430.00 390.00 322.50 292.50
M22 x 2.50 8.8 580.00 530.00 435.00 397.50
M24 x 3.00 8.8 740.00 670.00 555.00 502.50
M6 x 1.00 10.9 15.50 14.00 11.63 10.50
M8 x 1.25 10.9 37.00 34.00 27.75 25.50
M10 x 1.50 10.9 75.00 68.00 56.25 51.00
M12 x 1.75 10.9 160.00 117.00 97.50 87.75
M14 x 2.00 10.9 205.00 185.00 153.75 138.75
M16 x 2.00 10.9 310.00 280.00 232.50 210.00
Metric Torque Chart

Frontier TD2427 Specifications

General

Brand	Frontier
Model	TD2427
Category	Tedders
Language	English
