24
Chassis Assembly
1
2
3
4
5
6
7
8
9
10
11
13
12
14
15
16
17
18
19
20
Ref# Description Part# Ref# Description Part#
1 PTO Shield 5PQ702333 11 Hose Block Kit 5PQ507294
2 Bolt, 1/2 x 1-1/2 5PQ000435 12 Plastic PTO Shield 5PQ701205
3 Flange Bearing 5PQ500067 13 Plastic Guide 5PQ702436
4 Drive Line 5PQ700917 14 Jack Handle 5PQ500010
5 Flange Bearing 5PQ500067 15 Pin & Chain 5PQ102121
6 Bolt, 1/2 x 1-1/2 5PQ000435 16 Complete Jack 5PQ500009
7 Hose Support 5PQ502288 17 Hitch Bolt Kit 5PQ100079
8 Hose Support Washer 5PQ502308 18 Clevis Coupler 5PQ507018
9 Bolt, 5/16 x 1-1/4 5PQ000230 19 Complete PTO Shaft 5PQ701142
10 Owner’s Manual Canister 5PQ503050 20 Safety Chain 5PQ702201
