Frymaster FPH17 Series - Power Requirements

CHAPTER 5: POWER REQUIREMENTS
5-1
WARNING
For power supply connection, use copper wire only, suitable for at least 167°F(75°C).
MODEL VOLTAGE PHASE
WIRE
SERVICE
MIN.
SIZE
AWG
(mm
2
)
AMPS PER LEG
L1 L2 L3
H14 440 3 3 8 (10) 19 19 19
H14 (Sub) 440 3 3 8 (10) 19 19 19
H14 480 3 3 8 (10) 17 17 17
H17 440 3 3 6 (16) 23 23 23
H17 480 3 3 6 (16) 21 21 21
H22 440 3 3 6 (16) 29 29 29
H22 480 3 3 6 (16) 27 27 27
The FPH17 fryer is equipped with a filter system, which requires 120VAC, 20 amp service. The filter-
equipped fryer also has these power requirements per vat:
MODEL VOLTAGE PHASE
WIRE
SERVICE
MIN.
SIZE
AWG
(mm
2
)
AMPS PER LEG
L1 L2 L3
FPH*17 480 3 3 6 (16) 21 21 21
Filter 120 1 3 Standard cord 20
* Denotes number of vats. For example, an FPH317 has three vats.
The electrical power supply for the fryers MUST be the same as the voltage
indicated on the rating and serial number plate located on the fryer door.
