Frymaster FPH17 Series - Contactor Boxes; Parts Lists

CHAPTER 16: PARTS LISTS - H14, H17, H22, FPH17, H14
Sub
16-5
Submarine Fryer Contactor Box
Contactor Boxes
(Refer to Figure 16-3
ITEM # PART NO. DESCRIPTION FRYER MODEL
1 807-0064
Transformer, 480,440/120V
ALL
2 807-2464 3-Phase Power Input Terminal Block ALL
3 807-2181
Transformer, 120/24V for 440 or 480 fryers
ALL
4 807-0855
Transformer, 120/12V for 440 or 480V fryers only
ALL
5 807-0070 Terminal Lug, Ground ALL
6 810-2284 Contactor, Heating 3-pole, 50 Amp ALL
7 810-1202 Contactor, Latching 3-pole, 40 Amp ALL
8 807-0012 Relay, 18 Amp, 24 Volt coil ALL
9 807-1683 Relay, 12 Volt Coil ALL
10 807-0067 Terminal Block, 8 Pin ALL
11 807-0069 Circuit Breaker for 440 or 480V fryers ALL
12 806-7935 Interface Board ALL
13 809-0349 Spacer, Interface Board ALL
14 806-8364 Mounting Bracket, Interface Board
Submarine
15 807-0875 Connector, female 15-pin, Panel Mount
Surface Ship
* 806-2071 Wire Harness, (Control Panel to Interface Board)
Surface Ship
* 806-5095 Wire Harness, 5’ (Controller to Contactor Box)
Submarine
* 806-8346 Wire Harness, (Interface board to 15-pin connector)
Submarine
*Not illustrated.
