CHAPTER 13
CARE AND CLEANING OF THE FILTER SYSTEM
13-
4
M
Pump Relay Coil
Micro-switches
Pump Motor Switch
Pump Motor
Heater
24 VAC
Line Voltage
FootPrint III Wiring
Return Micro
Switches
