CHAPTER 16: PARTS LISTS - H14, H17, H22, FPH17, H14
Sub
16-2
Figure 16-1
Cabinet and Controllers
(Refer to Figure 16-1)
ITEM NO. PART NO. DESCRIPTION
1 824-0532
Tilt Housing Cover, Single Unit, SHIP
* 824-0534
Tilt Housing Cover, Double Unit, SHIP
* 824-0535
Tilt Housing Cover, Triple Unit, SHIP
* 824-0536
Tilt Housing Cover, Quad Unit, SHIP
2 824-0638
Element Housing, (SUB ONLY)
* 910-3122 Tilt Housing Cover Joining Strip (2, 3, or 4 fryers)
3 803-0028 Basket Hanger, all units
4 809-0171 Basket Hanger Screw
* 809-0015 Cage Nut
5 806-9166
Basket Hanger Bracket (SUB ONLY)
* 809-0079
Nut-sert (Submarine Basket Hanger)
6 806-3798
Analog Controller, (SURFACE SHIP)
7 806-9215
Analog Controller (SUB ONLY)
8 810-0387 Thermostat Knob, (all analog controllers)
9 806-8991
Controller Mounting Frame (SUB ONLY)
10 824-0697 Top Cap. Single (SUB)
* 824-0572
Top Cap, Single (SURFACE SHIP)
* 824-0571
Top Cap, Double (SURFACE SHIP)
* 824-0573
Top Cap, Triple (SURFACE SHIP)
* 824-0574
Top Cap, 4 fryers (SURFACE SHIP)
11 823-2901
Handle, Front, Triple, 47” (SURFACE SHIP)
* 823-2908
Handle, Front, Double, 31.4” (SURFACE SHIP)
* 900-07431
Door Hinge, (SURFACE SHIP)
12 823-2718
Handle, Front, single, 15.1” (SUB ONLY)
* 806-7543
High limit Thermostat, H14, H17
* 806-8536
High limit Thermostat, H22
13 823-2353
Leg, (Surface Ship)
FRYPOTS
Surface Ship Fryers
Part #
Without Built-in Filtration 823-2450
Built-in Filtration 823-2451
*Not illustrated.
