FUELL Flluid 1 - Seat Adjustment

Flluid 1
26
USING YOUR FLLUID
Seat Height Adjustment
WARNING
Not completely closing the quick release
lever (1) can result in the clamp open-
ing. This can cause the saddle to move
down while driving. This can lead to
serious injury.
Ifproperlytensionedtheipofthequick-
release lever should be heavy enough
that it requires the palm of your hand
to close.
Never raise seat higher than the marking
on the post (3).
The saddle can also be tilted and adjusted
in the longitudinal direction.
- Loosen the screw (1).
- Set the saddle in the desired horizontal
position or move it forwards or backwards
and tighten the screw (1)
NOTE
To avoid seat discomfort, the saddle should
be adjusted as level as possible.
Seat Adjustment
- Release quick release lever (1), adjust
seat height and tighten lock.
- By adjusting the nut (2) on the quick
release lever, the clamping force can be
adjusted.
The quick release lever (1) must be able
to close with a noticeable back pressure.
1
1
3 max.
2
