Flluid 1
58
MAINTENANCE
Steering Bearing
WARNING
Pay attention to maintenance intervals.
Driving for an extended time with a loose
steering bearing may cause a breakage
of the steering tube which can result in
a fall with serious injuries.
Inspect:
- With the handbrake lever pulled, move
the bike back and forth.
If play in the steering bearing (1) exists,
it must be readjusted.
To Adjust:
- Remove the cover (5) and loosen the
clamping screw underneath.
- Loosen the allen head screws (4).
- Adjust the steering bearing by adjust-
ing the clamping screw and tighten
the allen head screws (4).
NOTE
The front fork (4) must not jam when steering
and must swivel slightly in both directions.
CAUTION
Have this checked at an authorized
service center.
Steering Bearing Adjustment
At regular intervals, check the oil level in
the reservoirs.
Lubricate the brake lever pivot with grease
Check to be sure that all bolts are tightened
to the correct torque specications.
WARNING
Clean ller cap before removing. Use only
Tektro mineral oil brake uid from a sealed
container.
Pads should be replaced if they become
contaminated or have less than 2.5mm
thickness (Pad friction material and metal
backing plate).
.
Brake Inspection and Service
1
2
3
5
4
4
