FUELL Flluid 1 - Lock Operation and Tire Pressure

Flluid 1
38
USING YOUR FLLUID
Secure the vehicle against unauthorized
access.
To lock the Ring lock:
- Turn key (1) to the right and hold tight.
- At the same time push the lever (2) down
to the stop and release the key.
The lock is locked.
NOTE
The key can be removed in this position,
it cannot be removed when turned right.
To Open:
- Insert the key (1) into the lock and turn
to the right.
- The lever (2) opens.
The key is not removable when the lock
is open
NOTE
Note the key number by the key so that
replacement can be obtained if necessary.
Ring lock
Tire Pressure
Tires can be inated with an air compressor.
WARNING When inflating
the tires with compressor air pressure
equipment(egatllingstations)caution
is required. Due to the small volume of
the tires the max. pressure is achieved
quickly
Tire pressure front and rear max. 3.0 bar
(44 psi), min. 2.0 bar (29 psi).
1
2
