FUELL Flluid 1 - TECHNICAL DATA; Model Specifications Comparison

Flluid 1
60
TECHNICAL DATA
Modell FUELL Flluid 1 FUELL Flluid 1S FUELL Flluid 1E
E-Bike Class Class 1 (Pedelec) Class 3 (SpeedPedelec) Class 3 (SpeedPedelec)
General
Weight depending on the
equipment
About 31 kg / 69 lbs with battery
Perm. total weight max. 130 kg (287 lbs)
Perm. rear tray weight max. 18 kg (40lbs)
Dimensions (L x B x H) mm 1800 x 650 x 1200
Seat height mm (in) 930 (36.6) to max. 1120 (44)
Top Speed Pedal assist up to 32 kph
(20 mph)
Pedal assist up to 45 kph
(28 mph)
Pedal assist up to 45 kph (28 mph)
Chassis
Frame Aluminium
Fork Suntour XCM34 Boost 27.5” diameter 120 mm travel
Tire front and rear Pirelli 27.5" x 2.25
Tire pressure front and rear max. 3.0 bar (44 psi), min. 2.0 bar (29 psi)
Brake, Front Tektro HD-E 350 hydraulic disc brake; Ø180 mm
Brake, Rear Tektro HD-E 350 hydraulic disc brake; Ø180 mm
