FUELL Flluid 1 - Battery Charging

Flluid 1
36
USING YOUR FLLUID
Charging the Battery
- First connect the plug (3) of the charger
(4) to the wall outlet 100-230 V, 50-60
Hz.
- Open the cover (5) on the charge port.
- Connect the charging plug (6) of the
charger to the battery charge port.
NOTE
The battery (1) can be charged either in-
stalled into the Flluid or externally.
The battery is secured with a lock (2).
- Unlock the battery and remove it.
6
4
3
5
1
2
1
