Flluid 1
57
MAINTENANCE
Spokes
CAUTION
Have the drive belt tension inspected by
an authorized service center.
Inspect
- Put Flluid on the stand
- The drive belt (1) must be able to be
pressed down by approx. 10 mm.
- Use the Gates Carbon Drive mobile
apps for iPhone® and Android® via their
respective application marketplaces.
There is also a link on the Carbon Drive
Products page: https://www.gatescar-
bondrive.com/products/tools
Checking Drive Belt Tension
A tight t of the spokes (1) is important for
the proper running of the wheels. Spokes
can loosen over time, tighten as needed.
Cracked spokes and the spoke opposite
the cracked spoke must be replaced im-
mediately and re-tensioned. The wheel
may need to be re-trued.
Spoke failure and an imbalance of the wheel
often result from the improper tensioning
of spokes.
CAUTION
Replacing, tensioning or loosening
spokes is best completed by a service
center.
1
10 mm
1
