Unpacking:
Please make sure that the following materials are packaged in the Press Controller package. Load adjustment is carried out
using a pair of instruments for measuring and load-cell. Please make sure that the same serial number is placed on the each
product. Especially, pay attention when multiple units are purchased.
Package details:
Instrument body for measuring (serial No.: )
Load-cell (serial No.: )
※For some load-cells, cables having metal connector on both ends are packed separately.
Power source cable (with metal connectors): Special for AC 100V 50/60Hz
Cable for electromagnetic valve (with metal connectors)
※ Not pertained in case of mode 9.
SD memory card
Instruction manual (this document)
Serial No.
〈Front face of measuring instrument 〉 〈Load-cell〉
In the case that SD memory card is not inserted, the error will be occurred and then becomes
abnormal end.
Please always use after the insertion of SD memory card to the main body.
◎For the method of error cancellation, please refer to Page-22, “Error message of SD memory card”
and “Cancellation method.”
◎If the case that the SD memory card is not required, please consult with us separately.
◎Operation will not be guaranteed except the use of attached SD memory card.
To Next Page
