Stapler Faults
551
Problem Solving
15
Staple Jams in Staple Cartridge
(for Finisher-C1 or Finisher-C1 with Booklet Maker)
The following describes how to clear staple jam occurred in the staple cartridge of the
Finisher-C1 (optional) and the Finisher-C1 with Booklet Maker (optional).
This section describes the procedure to remove the jammed staples in the Finisher-C1
with Booklet Maker, as an example. You can apply the same procedure to the Finisher-
C1.
1 Make sure that the machine is not operating,
and open the finisher front door.
2 Grasp the handle [R1] of the staple cartridge
holder, and pull out the holder to the right,
towards you.
3 Pull out the staple cartridge.
Note • The staple cartridge is firmly inserted. A
slight force is required to pull the cartridge
out of the finisher.
4 After you pull out the staple cartridge, check
inside of the finisher for any remaining
staples.
[R1]
To Next Page
