16 Appendix
564
Appendix
16
îš„Finisher-B1 (Optional)
Stacker Capacity
z
Finisher Tray (For paper not stapled)
A4 : 500 sheets
B4 : 250 sheets
A3 or larger : 200 sheets
Mixed stack
*1
: 250 sheets
z
Finisher Tray (For paper stapled)
30 stapled sets
Important • When using 80 gsm paper
•
*1
Based on when larger size paper is stacked on paper.
Staple
z
Capacity
A4 : 50 sheets (60 - 90 gsm (56 - 90 gsm when
the HCF Kit (optional) is installed.))
B4 : 30 sheets (60 - 90 gsm (56 - 90 gsm when
the HCF Kit (optional) is installed.))
z
Paper Size
Maximum : A3, 11 × 17"
Minimum : B5
z
Position
1 place (front/angled stapling)
Dimensions/Weight Width 559 × Depth 448 × Height 246 mm, 12 kg
Space Requirement
(when connected to the
main unit)
Width 1,078 × Depth 1,104 mm (Main Unit + Finisher-A1)
Important • When the extension tray and the Tray 5 (Bypass) are fully
extended.
Type Finisher Tray × 1
Sorting (Offset available)/Stacking (Offset available)
Paper Size/
Paper Weight
z
Paper Size
Maximum: A3, 11 × 17", Minimum: B5
z
Paper Weight
60 - 216 gsm (56 - 216 gsm when the HCF Kit (optional) is
installed.)
Stacker Capacity
z
Finisher Tray (For paper not stapled)
A4 : 2,000 sheets
B4 or larger : 1,000 sheets
Mixed stack
*1
: 300 sheets
z
Finisher Tray (For paper stapled)
A4 : 100 sets or 1,000 sheets
B4 or larger : 75 sets or 750 sheets
Center binding/folding
*2
: 50 sets or 600 sheets
Folding
*2
: 500 sheets
Important • When using 80 gsm paper
•
*1
Based on when larger size paper is stacked on paper.
•
*2
For the center binding/folding specified was output,
remove the output paper from the tray to output the next job.
In addition, when you print a job with center binding/folding
specified and smaller-sized paper remains on the output
tray, remove the paper from the tray first.
To Next Page
