16 Appendix
568
Appendix
16
îš„Side Tray (Optional)
îš„Two Tray Module (Optional)
îš„
Tandem Tray Module (Optional)
îš„HCF Kit (Optional)
Paper Size Same as the Copy function
Paper Capacity 100 sheets
Important • When using 80 gsm paper
Dimensions/Weight Width 274 × Depth 469 × Height 128 mm, 1 kg
Space Requirement
(when connected to the
main unit)
Width 990 × Depth 1,104 mm
Important •
When the Tray 5 (Bypass) are fully extended.
Paper Size Maximum : A3 (297.0 × 420.0 mm),
: 11 × 17" (279.4 × 431.8 mm)
Minimum : A5 (148.0 × 210.0 mm)
Paper Weight 60 - 216 gsm
Paper Capacity 1,000 sheets (500 × 2)
Important • When using 80 gsm paper
Dimensions/Weight Width 540 × Depth 605 × Height 278 mm, 25 kg
Space Requirement
(when connected to the
main unit)
Width 990 × Depth 1,104 mm (Main Unit + Two Tray Module)
Important • When the Tray 5 (Bypass) is fully extended.
Paper Size A4 , B5 , 8.5 × 11"
Paper Weight 60 - 216 gsm
Paper Capacity 2,000 sheets (870 + 1,130)
Important • When using 80 gsm paper
Dimensions/Weight Width 540 × Depth 605 × Height 278 mm, 31.1 kg
Space Requirement
(when connected to the
main unit)
Width 1,090 × Depth 1,104 mm (Main Unit + Tandem Tray
Module)
Important • When the Tray 5 (Bypass) is fully extended.
Paper Size A4 , B5 , 8.5 × 11"
Paper Weight 56 - 216 gsm
Paper Capacity 2,000 sheets
Important • When using 80 gsm paper
Dimensions/Weight Width 389 × Depth 610 × Height 380 mm, 29 kg
Space Requirement
(when connected to the
main unit)
Width 1,050 × Depth 1,112 mm
(Main Unit + HCF)
Important •
When the Tray 5 (Bypass) is fully extended.
To Next Page
