Proxy Server Setup
Select the proxy server specification from [Same Proxy for All Protocols] or [Different Proxy
for Each Protocol]. When [Different Proxy for Each Protocol] is selected, you can configure
the HTTPS proxy server and HTTP proxy server, respectively.
When [Same Proxy for All Protocols] is selected, the settings for the HTTPS proxy server are
copied to those of the HTTP proxy server.
HTTPS Proxy Server Name
Enter the HTTPS proxy server name or the IP address. Up to 255 characters are allowed.
You can specify the addresses by IPv4 address, IPv6 address, and FQDN.
HTTPS Proxy Server Port Number
Set the HTTPS proxy server port number from 1 to 65535.
The default value is 8080.
z
Do not use the numbers assigned to the other ports.
HTTPS Proxy Server Authentication
Select [Enabled] when authentication is required to connect to the HTTPS proxy server.
HTTPS Proxy Server Login Name
Enter a login name of the HTTPS proxy server. Up to 31 characters are allowed.
HTTPS Proxy Server Password
Enter a password of the HTTPS proxy server. Up to 31 characters are allowed.
HTTP Proxy Server Name
Enter the server name or IP address of the HTTP proxy server. Up to 255 characters are
allowed. You can specify the addresses by IPv4 address, IPv6 address, and FQDN.
HTTP Proxy Server Port Number
Set the HTTP proxy server port number from 1 to 65535.
The default value is 8080.
z
Do not use the numbers assigned to the other ports.
HTTP Proxy Server Authentication
Select [Enabled] when authentication is required to connect to the HTTP proxy server.
HTTP Proxy Server Login Name
Enter a login name of the HTTP proxy server. Up to 31 characters are allowed.
HTTP Proxy Server Password
Enter a password of the HTTP proxy server. Up to 31 characters are allowed.
