270 Maintenance
6 Turn the waste toner box lock lever 90-degrees clockwise to lock the waste toner box.
7 Close the side cover.
NOTE:
• After replacing the belt unit, be sure to initialize its life counter. For details, see "Reset Trans Unit" on page 183.
Removing the 2nd BTR
1 Pinching the tabs on both sides of the 2nd BTR, lift it out of the printer.
