 Rear View
1 Control Board 6 Duplexer
2 Control Board Cover 7 2nd BTR
3 Ethernet Port 8 Fusing Unit
4
Wireless Adapter Socket (The optional
wireless adapter is not supplied in some
regions.)
9 Power Connector
5 USB Port 10 Rear Cover
