4.1.3 Preparation before a test run--Configuring function code data
Before running the motor, configure function code data specified in Table 4.1 in accordance with
the motor ratings and your system design values. The motor ratings are printed on the nameplate
of the motor. For your system design values, ask system designers about them.
• For details about how to change function code data, refer to Chapter 3, Section 3.4.1 "Setting
the function codes – "Data Setting." Refer to the function code H03 in Chapter 5 "FUNCTION
CODES" for the factory defaults of motor parameters. If any of them is different from the
default setting, change the function code data.
Table 4.1 Settings of Function Code Data before a Test Run
Function
code
Name Function code data
Factory setting
F04
Base frequency
Motor ratings
(printed on the
nameplate of
the motor)
60.0 (Hz)
F05
Rated voltage
at base frequency
0 (V)
0 (V)
P02
Motor parameter
(Rated capacity)
Applicable motor rated capacity
P03
Motor parameter
(Rated current)
Rated current of applicable motor
P99
Motor selection
0: Motor characteristics 0 (Fuji
standard 8-series motors)
F03
Maximum
frequency
System design values
* For a test-driving of
the motor, increase
values so that they are
longer than your sy
stem
design values. If the
set time is short, the
inverter may not start
running the motor.
60.0 (Hz)
F07
Acceleration time1*
6.00 (s)
F08
Deceleration time1*
6.00 (s)
