Data for F02 Run Command Source Description
3
Keypad
(Reverse rotation)
Enable / keys to run and stop the motor.
Note that this run command enables only the
reverse rotation.
There is no need to specify the rotation direction.
• When function code F02 = 0 or 1, the "Run forward" FWD and "Run reverse"
REV
terminal commands must be assigned to terminals [FWD]
and [REV],
respectively.
• When the FWD or REV is ON, the F02 data cannot be changed.
• When assigning the FWD or REV to terminal [FWD] or [REV] with F02
being set to "1," be sure to turn the target terminal OFF beforehand;
otherwise, the motor may unintentionally rotate.
• In addition to the run command sources described above, higher priority
command sources including communications link are provided.
F03 Maximum Frequency 1
F03 specifies the maximum frequency (for motor 1) to limit the output frequency.
Specifying the maximum frequency exceeding the rating of the equipment driven by
the inverter may cause damage or a dangerous situation. Make sure that the
maximum frequency setting matches the equipment rating.
The inverter can easily accept high-speed operation. When changing the speed setting,
carefully check the specifications of motors or equipment beforehand.
Otherwise injuries could occur.
Modifying F03 data to allow a higher reference frequency requires also changing
F15 data specifying a frequency limiter (high).
F04 Base Frequency 1
F05 Rated Voltage at Base Frequency 1
F06 Maximum Output Voltage 1
H50, H51 Non-linear V/f Pattern 1 (Frequency and Voltage)
H52, H53
Non-linear V/f Pattern 2 (Frequency and Voltage)
 Base Frequency 1 (F04)
Set the rated frequency printed on the nameplate labeled on the motor.
5-20
