FujiFilm FVR-Micro - Frequency Arrival Signal - FAR; Inverter Running - RUN

The table below lists functions that can be assigned to terminals [Y1] and [30A/B/C].
To make the explanations simpler, the examples shown below are all written for the normal
logic (Active ON).
Function code data
Functions assigned
Symbol
Active ON Active OFF
0 1000 Inverter running
RUN
1 1001 Frequency arrival signal
FAR
2
1002
Frequency detected
FDT
3
1003
Under voltage detected (Inverter stopped)
LU
5
1005
Inverter output limiting
IOL
6
1006
Auto-restarting after momentary power failure
IPF
7
1007
Motor overload early warning
OL
26 1026 Auto-resetting
TRY
35 1035 Inverter running 2
RUN2
36 1036 Overload prevention control
OLP
37
1037
Current detected
ID
38
1038
Current detected 2
ID2
41
1041
Low current detected
IDL
43
1043
Under PID control
PID-CTL
44
1044
Motor stopped due to slow flowrate under PID
control
PID-STP
56
1056
Motor overheat detected by thermistor (PTC)
THM
57 1057 Brake signal
BRKS
59 1059 Terminal [C1] wire break
C1OFF
84 1084 Maintenance timer
MNT
87
1087
Frequency arrival detected
FARFDT
90
1090
Traverse Up
TRV_UP
91
1091
Traverse Out
TRV_OUT
99
1099
Alarm output (for any alarm)
ALM
 Inverter running -- RUN (Function code data = 0)
This output signal tells the external equipment that the inverter is running at a starting frequency
or higher. It comes ON when the output frequency exceeds the starting frequency, and it goes
OFF when it is less than the stop frequency. It is also OFF when the DC braking is in operation.
If this signal is assigned in negative logic (Active OFF), it can be used as a signal indicating
"Inverter being stopped."
 Frequency arrival signal -- FAR (Function code data = 1)
This output signal comes ON when the difference between the output frequency and reference
frequency comes within the frequency arrival hysteresis width specified by E30. (Refer to the
description of E30.)
5-50
