01-25
- 20°C
Cooling Heating
1-25. COMPRESSOR STOP CONTROL
When the detection value of outdoor temperature sensor is lower than temperature in the table below,
the compressor is stopped.
(Table 15 : Operation temperature of compressor stop control)
Operation
temperature
Temperature
When the compressor temperature sensor detects higher than 108°C,
the compressor is stopped.
The protection is released when the compressor temperature sensor detects 80°C
after 3 minutes of compressor stop.
6. COMPRESSOR TEMPERATURE PROTECTION
7. HIGH PRESSURE PROTECTION
When the pressure switch becomes OFF (Open : higher than 609.2 psi / 4.2 MPa),
the compressor is stopped.
It is released when the pressure switch becomes ON (Close : lower than 464.1 psi / 3.2 MPa)
after 3 minutes of compressor stop.
