Check Point 3 : Check Outdoor Fan
OK
OK
Check Point 5 : Replace Main PCB
OK
OK
Check Point 1 : Check connections of Outdoor Unit Electrical Components
1. Defective connection of electric components 2. Outdoor Fan Operation failure
3. Outdoor Heat Exchanger clogged 4. Compressor failure 5. Main PCB failure
Check if the terminal connection is loose.
Check if connector is removed.
Check erroneous connection.
Check if cable is open.
>> Upon correcting the removed connector or mis-wiring, reset the power.
Check Point 2 : Check Outdoor Fan, Heat Exchanger
Is there anything obstructing the air distribution circuit?
Is there any clogging of Outdoor Heat Exchanger?
Is the Fan rotating by hand when operation is off ?
>> If the Fan Motor is locked, replace it.
Check Outdoor Fan Motor. (Refer to Trouble shooting 19)
>> If the Fan Motor is failure, replace it.
Check Point 4 : Check Compressor
Check Compressor. (PARTS INFORMATION 2)
If Check Point 1 4 do not improve the symptom, change Main PCB.
When more than normal operating current to IPM in Main PCB flows,
the compressor stops.
After the compressor restarts, if the same operation is repeated within
40sec, the compressor stops again.
If and repeats 5 times, the compressor stops permanently.
02-19
Outdoor Unit Main PCB Circuit
Compressor
Trouble shooting 15
OUTDOOR UNIT Error Method:
Indicate or Display:
Refer to error code table.
IPM error (Permanent Stop)
Detective Actuators: Detective details:
Forecast of Cause:
To Next Page
