Operation status output
Corresponding indoor units : All indoor units
Contents of operation : An air conditioner operation status signal can be output.
Circuit diagram example
Procured at the site
Display
Indoor
control PC board
Relay circuit
1
2
Signal
Relay
power
supply
5 to 24V
V
CN103
ON
OFF
ON
OFF
Air conditioner
Signal
