Fujitsu ARXC36L - 6 Electrical Wiring

En-8
OK
NOGOOD
INSTALL THE DRAIN PIPE
1
Main drain
On the main drain, provide one trap near the indoor unit.
Trap
H2
H1
H
1
=100mm(Approx.)
H
2
=50-100 mm
Unit
Drainpipe(Main)
2
Safety drain
There is no need to provide a trap for the safety drain.
If the safety drain is connected to the main drain, make the
connection below the main trap.
Drainpipe(Main)
Unit
Drainpipe(Safety)
• Makesurethatdrainpipeisinstalledwithoutrises.
• Donotperformairbleeding.
Rise
Air bleeding
Rise
NO GOOD
CAUTION
•Besuretoproperlyinsulatethedrainpipes.
•Makesurethedrainwaterisproperlydrained.
6. ELECTRICAL WIRING
]
WARNING
•Electricalworkmustbeperformedinaccordancewiththis
Manualbyapersoncertiedunderthenationalorregional
regulations. Be sure to use a dedicated circuit for the unit.
An insufficient power supply circuit or improperly
performed electrical work can cause serious accidents
suchaselectricshockorre.
•Before starting work, check that power is not being
supplied to the indoor unit and outdoor unit.
•Use the included connection cables and power cables
or ones specified by the manufacturer. Improper
connections, insufficient insulation, or exceeding the
allowablecurrentcancauseelectricshockorre.
•For wiring, use the prescribed type of cables, connect
them securely, making sure that there are no external
forces of the cables applied to the terminal connections.
Improperly connected or secured cables can cause
serious accidents such as overheating the terminals,
electricshock,orre.
•Do not modify the power cables, use extension cables,
or use any branches in the wiring. Improper connections,
insufcientinsulation,orexceedingtheallowablecurrent
cancauseelectricshockorre.
•Matchtheterminalboardnumbersandconnectioncable
colors with those of the outdoor unit. Erroneous wiring
may cause burning of the electric parts.
•Securely connect the connection cables to the terminal
board. In addition, secure the cables with wiring holders.
Improper connections, either in the wiring or at the ends
of the wiring, can cause a malfunction, electric shock, or
re.
•Alwaysfastentheoutsidecoveringoftheconnection
cable with the cable clamp. (If the insulator is chafed,
electric leakage may occur.)
•Securelyinstalltheelectricalboxcoverontheunit.
Animproperlyinstalledelectricalboxcovercancause
seriousaccidentssuchaselectricshockorrethrough
exposuretodustorwater.
•Installsleevesintoanyholesmadeinthewallsforwiring.
Otherwise, a short circuit could result.
•Installagroundleakagebreaker.Inaddition,installthe
ground leakage breaker so that the entire AC main power
supply is cut off at the same time. Otherwise, electric
shockorrecouldresult.
•Installagroundleakagebreaker.
If a ground leakage breaker is not installed, it may cause
electricshockorre.
•Alwaysconnectthegroundcable.
Improper grounding work can cause electric shocks.
•Installtheremotecontrolcablessoasnottobedirect
touched with your hand.
•Performwiringworkinaccordancewithstandardssothat
the air conditioner can be operated safely and positively.
•Connecttheconnectioncablermlytotheterminal
board.Imperfectinstallationmaycauseare.
