Fujitsu ASHG12LMCA User Manual

6. SYSTEM DESIGN
FUNCTION DETAILS5-6.
Functions
Compact
cassette
Slim duct Wall mounted Floor / Ceiling Floor
1) Filter sign
    
2) Ceiling height

- -

-
3) Outlet directions

- - - -
4) ertica airow direction range contro - - - -

5) Static pressure -

- - -
6) Room temperature control for cooling
    
7) Room temperature control for heating
    
8) Auto restart
    
9) Room temperature sensor switching
    
10) Remote controller custom code
    
11) External input control
    
12) Room temperature sensor switching (Aux.)
    
13)
Indoor unit fan control for energy saving
for cooling
    
1) Filter sign
eect appropriate interas or dispaing the ter sign on the indoor unit according to the
estimated amount of dust in the air of the room.
If the indication is not required, select "No indication" (03).
(

... Factory setting)
Setting description Function number Setting value
Standard
11
00
Long interval 01
Short interval 02

No indication 03
Intervals will differ depending on the Indoor unit type as follows.
Setting description
Comapact
Cassette
Slim Duct
Wall
Mounted
Floor /
Ceiling
Floor
Standard 2500 hours 400 hours
Long interval 4400 hours 1000 hours
Short interval 1250 hours 200 hours
2) Ceiling height
Select the appropriate ceiling height according to the place of installation.
(

... Factory setting)
Setting description Function number Setting value

Standard (2.7m)
20
00
High ceiling (3.0m) 01
In case of Cassette type models: The ceiling height values are for the 4-way outlet.
Do not change this setting in the 3-way outlet mode.
7000, 9000 Btu/h models cannot be installed in high
ceilings. Do not change this setting.
- (06 - 84) -
SYSTEM DESIGN SYSTEM DESIGN

Fujitsu ASHG12LMCA Specifications

General

Type	Split system
Timer	Yes
Multi-split	-
Product color	White
Dehumidifying capacity	1.8 l/h
Timer duration (maximum)	24 h
Air conditioner functions	Cooling, Dehumidifying, Heating
Cooling capacity in watts (max)	3900 W
Cooling capacity in watts (min)	900 W
Heating capacity in watts (max)	5300 W
Cooling capacity in watts (nominal)	3400 W
Cooling energy efficiency (EER, W/W)	3.5
Heating energy efficiency (COP, W/W)	3.92
Seasonal efficiency rating (cooling) (SEER)	7
Heating capacity in watts (nominal) (Warmer heating season)	- W
Heating capacity in watts (nominal) (Average heating season)	4000 W
Seasonal efficiency rating (heating) (SCOP) (Average heating season)	4
AC input voltage	230 V
AC input frequency	50 Hz
Design load (cooling)	- kW
Energy efficiency class (cooling)	A++
Power consumption (cooling) (max)	970 W
Power consumption (heating) (max)	1020 W
Annual energy consumption (cooling)	170 kWh
Hourly energy consumption (cooling)	- kWh
Energy efficiency class (heating) (Average heating season)	A+
Annual energy consumption (heating) (Average heating season)	1225 kWh
Indoor unit type	Wall-mountable
Indoor unit depth	203 mm
Indoor unit width	840 mm
Indoor unit height	268 mm
Indoor unit weight	8500 g
Indoor unit noise level (high speed)	43 dB
Outdoor unit depth	293 mm
Outdoor unit width	663 mm
Outdoor unit height	535 mm
Outdoor unit weight	26000 g
Outdoor unit noise level	50 dB
Airflow	750 m³/h
