6. SYSTEM DESIGN
3) Outlet directions
Select the appropriate number of outlet directions according to the installation conditions.
(

... Factory setting)
Setting description Function number Setting value

4-way
22
00
3-way 01
4) Vertical airow direction range control
In a concealed installation, change the setting to "Fixed" (02) to restrict the movement of the
upper air outet so that the airow is on towards the horionta direction.
(

... Factory setting)
Setting description Function number Setting value

Standard
23
00
(Setting forbidden) 01
Fixed (Concealed) 02
5) Static pressure
Select the appropriate static pressure according to the installation conditions.
(

... Factory setting)
Setting description Function number Setting value
0 Pa
26
00
10 Pa 01
20 Pa 02
30 Pa 03
40 Pa 04
50 Pa 05
60 Pa 06
70 Pa 07
80 Pa 08
90 Pa 09

25 Pa [Standard] 31
6) Room temperature control for cooling
Depending on the installed environment, correction of the room temperature sensor may be
required.
Select the appropriate control setting according to the installed environment.
(

... Factory setting)
Setting description Function number Setting value

Standard
30
00
Slightly lower control 01
Lower control 02
Higher control 03
n case o i duct tpe and ooreiing tpe odes n oor consoe instaations seect
"01".
7) Room temperature control for heating
Depending on the installed environment, correction of the room temperature sensor may be
required.
Select the appropriate control setting according to the installed environment.
(

... Factory setting)
Setting description Function number Setting value

Standard
31
00
Lower control 01
Slightly higher control 02
Higher control 03
n case o i duct tpe and ooreiing tpe odes n oor consoe instaations seect
"01".
- (06 - 85) -
SYSTEM DESIGN SYSTEM DESIGN

Fujitsu ASHG12LMCA Specifications

General

Type	Split system
Timer	Yes
Multi-split	-
Product color	White
Dehumidifying capacity	1.8 l/h
Timer duration (maximum)	24 h
Air conditioner functions	Cooling, Dehumidifying, Heating
Cooling capacity in watts (max)	3900 W
Cooling capacity in watts (min)	900 W
Heating capacity in watts (max)	5300 W
Cooling capacity in watts (nominal)	3400 W
Cooling energy efficiency (EER, W/W)	3.5
Heating energy efficiency (COP, W/W)	3.92
Seasonal efficiency rating (cooling) (SEER)	7
Heating capacity in watts (nominal) (Warmer heating season)	- W
Heating capacity in watts (nominal) (Average heating season)	4000 W
Seasonal efficiency rating (heating) (SCOP) (Average heating season)	4
AC input voltage	230 V
AC input frequency	50 Hz
Design load (cooling)	- kW
Energy efficiency class (cooling)	A++
Power consumption (cooling) (max)	970 W
Power consumption (heating) (max)	1020 W
Annual energy consumption (cooling)	170 kWh
Hourly energy consumption (cooling)	- kWh
Energy efficiency class (heating) (Average heating season)	A+
Annual energy consumption (heating) (Average heating season)	1225 kWh
Indoor unit type	Wall-mountable
Indoor unit depth	203 mm
Indoor unit width	840 mm
Indoor unit height	268 mm
Indoor unit weight	8500 g
Indoor unit noise level (high speed)	43 dB
Outdoor unit depth	293 mm
Outdoor unit width	663 mm
Outdoor unit height	535 mm
Outdoor unit weight	26000 g
Outdoor unit noise level	50 dB
Airflow	750 m³/h
