• Settingdetails
Function
number
Item Setting number
01 Indoor unit address 00~63
02 Refrigeration address 00~99
For use with a remote control, set all rotary switches to 0, and
referto“7.1.Settingtheaddress”fordetails.
All switches are set to 0 at the factory.
(2) Others
Indication pattern
Indicator Name Indication pattern
OPERATION
indicatorlamp(Green)
Function number; tens place
(0.5s ON/0.5s OFF)
TIMER indicator
lamp (Orange)
Function number; ones place (0.5s
ON/0.5s OFF)
FILTER indicator
lamp (Red)
Settingnumber:(0-9)(0.5sON/0.5s
OFF)
(Example)Function:31,Settingnumber:2
OPERATION
indicator lamp
(Green)
TIMER
indicator lamp
(Orange)
FILTER
indicator lamp
(Red)
11 sec
10 sec
9 sec
1 cycle 12 sec
ON
OFF
0.5s
0.5s
0.5s
0.5s
0.5s
0.5s
0.5s
0.5s
0.5s
0.5s 0.5s 0.5s
ON
OFF
ON
OFF
7.3.1. Button name and function
OPERATIONindicatorlamp(Green)
FILTER indicator lamp (Red)
TIMER indicator lamp (Orange)
7.3.2. Checking the function settings
• Pressandholdthe“MANUALAUTO”buttonontheindoor
unit for 3 seconds to check the function settings. It is
necessary to disconnect the power in order to return to
normal operation mode.
(1) Indoor unit and refrigerant address indication
Indication pattern
Indicator name
Indication pattern
Indoor unit
address
Refrigerant address
OPERATION
indicatorlamp(Green)
ON
Flash
(1.0s ON/1.0s OFF)
TIMER indicator
lamp (Orange)
Address:tensplace(0.5sON/0.5sOFF)
FILTER indicator
lamp (Red)
Address:onesplace(0.5sON/0.5sOFF)
• Indoorunitaddressexample
(Example)ADDRESS:24
OPERATION
indicator lamp
(Green)
TIMER
indicator lamp
(Orange)
FILTER
indicator lamp
(Red)
10 sec
1 cycle 12 sec
8 sec
ON
OFF
0.5s
0.5s 0.5s 0.5s
0.5s
0.5s
0.5s 0.5s
0.5s
0.5s
0.5s 0.5s
ON
OFF
ON
OFF
ON
• Refrigerantaddressexample
(Example)ADDRESS:30
OPERATION
indicator lamp
(Green)
TIMER
indicator lamp
(Orange)
FILTER
indicator lamp
(Red)
9 sec
1 cycle 12 sec
ON
OFF
1.0s 1.0s 1.0s
1.0s 1.0s 1.0s 1.0s
0.5s
0.5s
0.5s 0.5s 0.5s 0.5s
ON
OFF
ON
OFF
OFF
