Name and Shape Q’ty Application
Operation Manual
1
Installation Manual
1
(This book)
Wall hook bracket
1
For indoor unit
installation
Tapping screw (Big)
(M4 × 20mm)
12
For wall hook
bracket installation
Insulation
(Drainhose)
1
Adhesive type
105×600
3. INSTALLATION WORK
Especially, the installation place is very important for the split
type air conditioner because it is very difcult to move from
placetoplaceaftertherstinstallation.
]1
3.1. Selecting an installation location
Decide the mounting position together with the customer as
follows.
WARNING
•Selectinstallationlocationsthatcanproperlysupportthe
weight of the indoor unit. Install the units securely so that
they do not topple or fall.
CAUTION
Donotinstalltheindoorunitinthefollowingareas:
•Areawithhighsaltcontent,suchasattheseaside.Itwill
deteriorate metal parts, causing the parts to fall or the
unit to leak water.
•Area lledwithmineral oil or containingalarge amount
of splashed oil or steam, such as a kitchen. It will
deteriorate plastic parts, causing the parts to fall or the
unit to leak water.
•Areathatgeneratessubstancesthatadverselyaffectthe
equipment, such as sulfuric gas, chlorine gas, acid, or
alkali. It will cause the copper pipes and brazed joints to
corrode, which can cause refrigerant leakage.
•Area that can cause combustible gas to leak, contains
suspended carbon bers or ammable dust, or volatile
inflammables such as paint thinner or gasoline. If gas
leaksandsettlesaroundtheunit,itcancauseare.
•Areawhereanimalsmayurinateontheunitorammonia
may be generated.
•Donotusetheunitforspecialpurposes,suchasstoring
food, raising animals, growing plants, or preserving
precision devices or art objects.
It can degrade the quality of the preserved or stored
objects.
•Do not install where there is the danger of combustible
gas leakage.
•Do not install the unit near a source of heat, steam, or
ammablegas.
•Install the unit where drainage does not cause any
trouble.
•Install the indoor unit,outdoor unit,power supplycable,
transmission cable, and remote control cable at least 1 m
away from a television or radio receivers. The purpose of
this is to prevent TV reception interference or radio noise.
(Even if they are installed more than 1 m apart, you could
still receive noise under some signal conditions.)
•If children under 10 years old may approach the unit,
take preventive measures so that they cannot reach the
unit.
•Takeprecautionstopreventtheunitfromfalling.
(1) Installtheindoorunitonaplacehavingasufcient
strength so that it withstands against the weight of the
indoor unit.
(2) The inlet and outlet ports should not be obstructed; the air
should be able to blow all over the room.
(3) Leave the space required to service the air conditioner.
(4) Install the unit where connection to the outdoor unit is
easy.
(5) Install the unit where the connection pipe can be easily
installed.
(6) Install the unit where the drain pipe can be easily installed.
(7) Install the unit where noise and vibrations are not
amplied.
(8) Take servicing, etc., into consideration and leave the
spaces.Alsoinstalltheunitwheretheltercanbe
removed.
(9) Donotinstalltheunitwhereitwillbeexposedtodirect
sunlight.
]1
3.2. Installation dimension
For the drain hose
extension,usea
drain hose with a
16 mm inside diameter.
1800 mm
or over
1500 mm
or over
Right side
200 mm
or over
60 mm or over
Left
side
50 mm
or over
