Getting started
Adjusting the height
The height of the monitor c an b e adjusted by approximately 120 mm.
► Grasp the monitor w ith both hands on the right and left edge o f the casing
and move it upward or downward.
Adjusting the inclination
► Hold the monitor with b oth hand
s on the left and right sides of the casing
and move it to the desired angle
.
Adjusting the rotation
The monitor c an be horizontally rotated by ± 45° from its centre po sition.
► Grasp the monitor w ith both hands on the right and left edge o f the casing
and turn it to the desired position.
Adjusting portrait format
The monitor can be rotated from horizo ntal format (landscape mode) into
vertical format (portrait mode).
► Grasp the monitor with both hands on the right and left edge of the casing, move it into
the highest position and turn it clockwise until it is in the p ortrait position.
For you to be able to display the screen contents in portrait mode, your graphics card
will also need to supp ort this function or you will need to use special software.
In the OSD menu you have the option of switching the OSD manually
from landscape mode to portrait mod e (see "
Changing the monitor
settings using the OSD menu", Page 17).
To reset the monitor to landscape mode, the monitor should be turned anti-clockwise.
The OSD display can be reset again in the OSD menu.
10 A26361-K1317-Z220-1-7619, edition 2
