Getting started
Removing monitor base
Before you can use a swivel arm or a wall bracket, you must remove the monitor base.
The display surface is susceptible to scratching!
► Switch off the monitor and pull the power
plug out of the power socket.
► Lay the m onitor on its face on a soft surface.
► Remove all cables.
► To remove the m onitor base, undo the
screws on the monitor base.
You can now mount a sw ivel arm or a wall
bracket in a ccord ance with VESA F PMPMI
using a hole spacing of 100 mm.
For instructions on how to mount the
swivel arm or wall bracket, please
see the documentation for the swivel
arm or wall bracket.
For instructions on how to mount the swivel arm or wall bracket, please see
the documentation for the swivel arm or wall bracket.
A26361-K1317-Z220-1-761 9, edition 2 11
