PC Specialist's Handbook ErgoPro m664-series
Edition 1 - Release 1 - March 1998 Page 3-7
IRQ 10 Available (default)
Reserved
IRQ 11 Available (default)
Reserved
Peripheral Configuration
Configures peripheral ports and devices. When selected, the following Peripheral Configuration submenu
is displayed:
Serial port A
Configures serial port A. Auto assigns the first free COM port, normally COM1, the address 3F8h
and the interrupt IRQ 4. An * (asterisk) displayed next to an address indicates a conflict with
another device.
Disabled
Enabled
Auto (default)
Base I/O address
Specifies the I/O port address of the COM-port.
3F8 (default)
2F8
3E8
2E8
Interrupt
Specifies the interrupt of the COM-port.
IRQ 3
IRQ 4 (default)
Serial port B
Configures serial port B. Auto assigns the first free COM port, normally COM2, the address 2F8h and
the interrupt IRQ 3. An * (asterisk) displayed next to an address indicates a conflict with another device.
Disabled
Enabled
Auto (default)
Mode
Specifies the mode of the COM-port for normal and infrared applications.
Normal (default)
IrDA
ASK-IR
Base I/O address
Specifies the I/O port address of the COM-port.
3F8
2F8 (default)
3E8
2E8
Interrupt
Specifies the h/w interrupt of the COM-port.
IRQ 3 (default)
IRQ 4
Parallel port
Configures parallel port. Auto assigns LPT1 the address 378h and the interrupt IRQ 7. An * (asterisk)
displayed next to an address indicates a conflict with another device.
Disabled
Enabled
Auto (default)
