Installing the cable co ver (optiona
l)
Installing the cable cover (op
tional)
• All necessary lines a re conn ected to the de vice.
1
► Insert the latch of the cable cover (not shown here ) on the back of the assy slightly
obliquely into the eyelet, t o secure the cable cover (1).
3
2
► Run the lines out through the opening (2) in the cable cover (3).
► Slide the cable cover complete ly onto the assy.
Fujitsu 25
