Fujitsu ESPRIMO D70 Series - Technical Specifications; Electrical and Environmental Data; Ventilation and Dimension Specifications

Technical specifi cation
Technical specification
Electrical data
Protection class: I
Rated voltage range: 100 - 240 V
Rated frequency:
50 - 60 Hz
Max. rated current:
Device without monitor socket: 3,5 - 1,5 A
Device with monitor socket: 5,5 - 2, 5 A
of w hich Value for monitor s ocket:
2,0 - 1,0 A
Dimensions
Width/depth/height: 314 mm x 296 mm x 89 m m /
12,36 inch x 11,65 inch x 3,50 inch
Weight
In basic configuration: approx. 6.5 kg /
14,33 lbs
Environmental conditions
Environment class (3K2):
Environment class (2K2):
DIN IEC 721 part 3-3
DIN IEC 721 part 3-2
Temperature:
Operating (3K2): 10 °C … 35 °C / 50 °F … 95 °F
Transportation (2K2): -25 °C … 60 °C / -13 °F … 140 °F
The formation of condensation is not permitted while the device is in operation !
Clearance required to ensure adequate ventilation:
Without air v ents
With air vents
min. 10 mm / 0.39 inch
min. 200 mm / 7.87"
The data sheet for this device provides further technical data. The data sheet
can be found on our website "
http://fujitsu.com/fts/".
40 Fujitsu
