Getting started
Proceed as follows to operate the device in the v ertical operating position using the rubber feet:
Vertica lo perat i
ngposition
Operatingpositi
on,vertical
BasefeetSidecover
► Disconnect the cables if required.
► Position the cas i
ng vertically so that the ON/OFF s witch is located at the bottom.
► Pull off the foil from the rubber feet that you will find in the accessories packa ge.
40 mm
6 mm
1
1
1
1
► Affix the rubber feet (1) to the outside of the casing. The positions of the rubber feet
must correspond to the dimen sions given so tha t the device is stable.
► Stand t
he device on the rubber feet.
► Reconnect any cables which were disconnected earlier.
