System expansio ns
Assembling and dismantling low-profile units
Low-profileboar d
For every slot there is a slot cover provided. If no board is installed, t he slot c over protects the slot.
When you install a board, do not disca rd the corresponding slot cover.
For cooling, protection against fire and in order to comply with EM C regulations,
you must refit the slot cover if you remove the board.
Removing a slot cover
► Open the casing (see "Opening the casing", Page 33).
1
2
► Undo the screw (1).
► Pull the slot cover out of the slot (2).
Fujitsu Technology Solutions 49
