Fujitsu ESPRIMO E352 Series - Opening the Casing; Removing a Cover

System expansio ns
Opening the casing
Removing a cover
► Switch the device off.
The device must not be in the energy-saving m ode!
► Remove any plugged-in wires which are in the way.
1
1
► Loosen the screws (1).
3
2
► Pull the cover a small distance in the direction indicated by the arrow (2) and remove it (3).
Fujitsu Technology Solutions 33
