− 52/83 −
(3) Print Group
Item Description Setting Value
1
Paper Width
Paper width and number of characters
per line
1
2
3
4
80mm/48columns
80mm/42columns
58mm/35columns
58mm/32columns
2
Max Speed
Maximum print speed
The maximum for printing ladder
barcodes and two-dimensional codes
is 120mm/s.
1
2
3
4
5
6
7
8
9
100mm/s
110mm/s
120mm/s
130mm/s
140mm/s
150mm/s
160mm/s
170mm/s
180mm/s
3 Print Density
Print density
The smaller the value the lower the
print density.
The higher the value the higher the
print density.
1
2
3
4
5
6
7
70%
80%
90%
100%
110%
120%
130%
To Next Page
