Ports and operating elem en ts
Left side
DCinput connector(D C IN)Microphonepor tModemportUSBportFireW irep ortSm artCardread erPCcardslotExpressCar d slotCardeject buttonHeadphoneport /SPDIF
1234 5 6 78
9
9
10
1 = DC input connector (DC IN)
2 = Microphone port
3 = Headphone port
4 = Modem port
5=USBports
6 = FireWire port
7 = SmartCard reader
8 = PC card slot
9 = Card eject button
10 = ExpressCard slot
Right side
RightsideViewModuleKensington Lo
ck
12 3
1 = Kensington Lock
2 = Module
3 = Eject lever for module
A26391-K272-Z220-1 -7619 , edition 1 5
