Removing and in stalling componen ts
during servicing
Installing a memory module
Memory bank 0 must always be loaded.
2
a
1
► Insert the memo ry m odule with t
he contacts
and the recess (a) facing the
slot (1 ).
MemoryexpansionMemorymodule
► Carefully push the memory module
downwards until you feel it click
into place (2).
Attaching the cov er
2
1
► Place the cover in the correct
mounting position (1).
► Fasten the cover with the scre w (2).
► Reinstall the battery (see "
Install ing battery", Page 16).
► Turn the notebook the right way up and place it on a flat surface.
► Reconnect the cables that you d isconnected previously.
28 A26391-K272-Z220-1-7619, edition 1
