Connecting external de vices
Connecting an external monitor to the dock
An analog monitor is connected to the analog exte rnal monitor port (VGA) and a digital monitor to
the Display Port on the optional dock. The d isplay output is limited to a maximum of two monitors
atthesametime(see"
Hot Ke ys", Page 26, the section on "Toggling the display output").
MonitorVGA socketMonito rportMonitorp ort
Analog external monitor port (VGA) (on the
optional dock)
Digital D isplay Port (on the optional dock)
► Switch off the not
ebook a nd the external monitor.
► Plug the data cable of the external monitor into the monitor port.
► First switch on
the exte rnal monitor and then the notebook.
You can also swi
tch back and forth between the external monitor and the LCD
screen of the n
otebook, see chapter "
Hot Keys", Page 26.
You can displa
y the same picture on the external monitor and the
notebook LCD s
creen simultaneously.
Fujitsu 53
