Technical data
WLAN specifications
Type of ne twork Intel® Dual Band Wireless-AC 9560
11a/b/g/n/11ac), W i-Fi based*, with 264 bit
encryption
Transfer rate (Automatic switching) IEEE802.11 a and g: 54
Mbps max. data rate; IEEE802.11n: 300 Mbps
max. data rate, IEEE802.11ac: 867 Mbp s max.
data rate
Active frequency • 802.11n 2.4 GHz / 5 GHz
• 802.11b/g: 2400~2473 MHz
• 802.11a. 4900 ~5850 MHz
• 802.11a. 2.4 GHz / 5 G H z
Typica l operating distances** • 802.11a. 40 ft. (12 m) @ 54 Mbps; 300 ft.
(91m)@6Mbps
• 802.11ac 40 ft. (12 m) @ 54 Mbps; 300
ft.(91 m) @ 6 Mbps
• 802.11b 100 ft. (30 m) @ 11 Mbps; 300 ft.
(91m)@1Mbps
• 802.11g: 100 ft. (30 m) @ 54 M bps; 300 ft.
(91m)@1Mbps
• 802.11n Estimated: double the operating
distance of 802.11g and 802.11a in their
respective frequencies
Number of channels
• 802.11a. 8 independent channels
• 802.11b/g: 11 channels, 3 non-o verlapping
channels
• 802.11n C hannel bonding takes two of the
non-overlapping 20 MHz channels and
combines them into one 40 MHz channel. It
is actually 12 non-overlapping channels with
channel bo nding and 24 without. Also it is 1
non-overlapping channel in 2.4 GHz when
channel bonding is used.
• 802.11ac 5 independent channels
Maximum recommended number of com puters
to be connected over w ireless LAN (during ad
hoc connection)
≤ 10 units ****
*“Wi-
Fi based” means that the interconnectivity test of the organization tha t guarantees the
inter
connectivity of Wireless LAN (Wi-Fi Alliance) has been passed.
** Th
e operating distances given above increase or decrease depending on factors such as the
numb
er of walls, reflecting material or interference by external R F sources.
***
* Depending on the particular p ractical application, the number of computers which can be
net
worked is reduced if necessary.
70 Fujitsu
