XSCF>

showlogs

error

-v
Date:

Dec

20

10:50:05

JST

2013
Code:

80000480-001f010021ff00cc01-11000057d000000000000000
Status:

Alarm

Occurred:

Dec

20

10:49:59.136

JST

2013
FRU:

/MBU/PCI#1/LINK,/MBU/PCI#1/LINK/MGCBL,/MBU/PCI#1/PCIBOX#3001/LINKBD,*
Msg:

TWI

access

error
Diagnostic

Code:
00010000

00000000

0000
00010000

00000000

0000
00013330

30310000

0000
07100000

00000000

00000000

00000000
^^
00000000

00000000

0000
XSCF>

showlogs

event
Dec

20

10:49:59

JST

2013

Attach

operation

(/BB#0/PCI#1/
PCIBOX#3001/PCI#1)

Dec

20

10:49:59

JST

2013

Detach
operation

(/BB#0/PCI#1/PCIBOX#3001/PCI#1)
---

Omitted

---
Confirmation method of RTIF2-140902-002
The phenomenon of RTIF2-140902-002 can be checked in the following ways.
1. The phenomenon of RTIF2-140902-002 can be checked in the following ways.
- FRU displays "LINK" or "LINKBD"
- Msg displays "TWI access error"
- The first byte in the fourth line of the Diagnostic Code is "07"
[Example of incorrect registration]
2. When the
showlogs event command or showlogs error command are executed
on the same PCI expansion unit within 10 minutes, multiple logs shown below
are registered.
- 12 or more event logs related to the PCIe card are registered upon executing
the showlogs event command. The number of event logs is calculated as
follows depending on the event type.
- Event of PCIe card insertion: 2
- Event other than PCIe card insertion: 1
For example, if a PCIe card is repeatedly inserted and removed four times,
eight message lines are displayed. However, the number of registered event
logs is 12, which is
calculated by multiplying three events by four. This
applies to this case.
[Example of PCIe card insertion/removal]
- Six or more logs are registered by the PCI expansion unit firmware (the first
byte in the third field of Code is 11) upon executing the showlogs error
command.
