18 Options Guide RX200 S3
Pulling out / removing the server Preparation
If the server is difficult to reach in the rack after you have pulled it out, remove
it completely from the rack. If you do not want to remove the server, skip this
page.
V CAUTION!
There is no cable management for the server in the rack!
Before you remove the server from the rack, you must therefore unplug
all cables connected to the server from their sockets.
V CAUTION!
At least two people are needed to lift the server out of the rack.
Figure 3: Removing the server from the rack
Ê Press the safety springs (1) on both sides and carefully pull the server
forward a little (2).
Ê Pull the server off the rails and place it on a table or similar surface.
C
O
MPA
C
T
High Speed
COMP
A
C
T
High Speed
1
2
