RX200 S3 Options Guide 19
Preparation Opening the serve
r
4.2 Opening the server
Figure 4: Removing the top cover
Ê For removing the top cover press the cover button downward (1).
Ê Slide the cover approx. 1 cm towards the rear of the server and lift it off (2).
1
2
