Fujitsu PRIMERGY RX200 S3 Options Guide

RX200 S3 Options Guide 17
4 Preparation
V CAUTION!
Please observe the safety information in the chapter “Safety Instructions”
on page 11ff.
4.1 Pulling out / removing the server
Ê Exit all applications and shut down the server correctly.
Ê If your operating system has not switched off the sever, press the on/off
switch.
Ê Unplug the power plugs.
Figure 2: Pulling the server out of the rack
Ê Loosen the knurled screws (1) and pull the server carefully out of the
rack (2) as far as possible.
C
O
MPA
C
T
High Speed
COMP
A
CT
High Speed
1
1
2

Fujitsu PRIMERGY RX200 S3 Specifications

General

Number of Processors	2
Storage	Up to 6 x 3.5" SAS/SATA HDD
RAID Support	RAID 0, 1
Network	Dual Gigabit Ethernet
Form Factor	1U Rack
Power Supply	Hot-plug redundant power supply
