22 Options Guide RX200 S3
Population rules Main Memory
ā The module capacity between pairs can differ: e.g. pair 1A/1B can be
populated with two 512 Mbyte modules and pair 2A/2B with two 1 Gbyte
modules.
The table below shows the order in which the memory banks must be equipped:
Memory mirroring
Either 4 or 4+4 identical memory modules are required for memory mirroring:
Bank 1:
module pair
1A/1B
Bank 2:
module pair
1C/1D
Bank 3:
module pair
2A/2B
Bank 4:
module pair
2C/2D
Equipped Empty Empty Empty
Equipped Equipped Empty Empty
Equipped Equipped Equipped Empty
Equipped Equipped Equipped Equipped
Memory
bank
12 3 4
Channel
(module)
1A 1B 1C 1D 2A 2B 2C 2D
Equipment 4 identical memory modules - -
4 identical memory modules 4 identical memory modules
