38 Options Guide RX200 S3
Controllers in Non-Hot-Plug PCI Slots
ā— Type B: One slot each for a PCI-X and a PCIe controller
Slot #1: 64 bit/100 MHz, low-profile, max. length 175 mm
Slot #2: PCIe x8, max. length 315 mm
Figure 21: Riser card type B: 1*PCI-X and 1*PCIe-x8
I Both slots are not hot-pluggable.
Slot #1
Slot #2
